HL5319

GENERAL DESCRIPTION

The HL5319 is a low cost single chip ToyID® Reader that support ToyID®16 reading and read/write both HL5313A and ISO/IEC 14443A tag.  The built-in 13.56 MHz driver circuit can transmit power and data to tags directly.  There are two separated amplifiers and antenna drivers.  Each of them provides sufficient gain to amplify the modulation signals transmitted by tags with a few external components for digital data demodulation circuit in HL5319 at the different data rate.  The antenna of HL5319 could be designed as two standalone or one push-pull pair type to enhance the driving power.  The serial data interface transmitter of HL5309A is used to receive command data from external controller and to transmit the responded data to the controller.

FEATURES

  • Built in 13.56MHz clock oscillator and drivers
  • Built in 2 analog amplifiers and antennal drivers
  • Support ToyID®16, HL5313A and ISO/IEC 14443A tag
  • Separate or Share antenna application is easily to handle different kinds of Tag Accessing
  • 2-wire serial interface



ABSOLUTE MAXIMUM RATING

Supply Voltage (VDD to GND)--------------- 6V

Input Voltage Range---------------------------- (GND - 0.3V) to (VDD + 0.3V)

Operating Temperature Range----------------- 0℃ to +60℃

Strong Temperature----------------------------- -65℃ to +125℃



ELECTRICAL CHARACTERISTICS

VDD=5V, GND=0V, Ta=+25°C, unless otherwise noted.

DESCRIPTION

TEST CONDITION

LIMIT

UNIT

MIN.

TYP.

MAX.

Operating Voltage



3.3



5.5

V

Standby Current

ENB=0V



0.2

10

μA

Operating Current

VDD=5V



25



mA

Operating Frequency

VDD=5V



13.56



MHz

Input low voltage

pin : ENB, ISCK, ISDA , IADR





1.5

V

Input high voltage

pin : ENB, ISCK, ISDA, IADR

3.5





V

Output low voltage

Iout = -0.1mA
pin : ISDA, SPIDO, SPICOM, SDO





1.0

V

Output high voltage

Iout = 0.1mA
pin : ISDA, SPIDO, SPICOM, SDO

4.0





V



Note: Operating Current depends on external coil



APPLICATION CIRCUIT



Figure 1: HL5319 Block Diagram

SERIAL DATA INTERFACE FORMAT

MCU Write data to HL5319

Figure 2

MCU Read data from HL5319

Figure 3
